Model

OTM156-RPC03-AIO

Display Technology

Active Matrix TFT-LCD with LED Backlight

Aspect Ratio

16:9

Active Area (H × V)

344.16× 193.59mm

Native Resolution

1920×1080@60Hz

Response Time (Typ.)

30ms

Display Colors

16.7M

Brightness   (typical)

220 cd/m² (Typ.)

Contrast Ratio (Typ.)

800:1

Viewing Angle (Typ.)

Horizontal (left/right) CR≥10 85°/85°

Vertical (up/down) CR≥10 85°/85°

Computer   Parameters

Windows Computer

Android Computer

Processor

J3455/i3/i5/i7

Processor

Rockchip   RK3388,RK3399

Memory

4G/8G/16G

Memory

2G/4G

Storage

64G/120G/240G

Storage

8G/16G/32G

OS

Windows   7/8/10 /Linux

OS

Android   7.1/8.1/10.1

I/O

USB,COM,LAN,WLAN,Audio

I/O

LAN,WLAN,USB,SD,Audio

Touch Screen Parameters

Touch Technology

Projected Capacitive (PCAP)

Surface Treatment

Tempered Strengthened

Optional:AG /AR

Thickness(Total)

2.75±0.2mm

Light Transmission

≥83%

Response Time

8ms

Touch Screen Interface

USB

Touch Point

10

Overal Parameters

Case/Bezel Color

Black

Mounting Options

75×75 mm

Outline Dimensions（W×H×D）

401.5mm × 250.7mm× 39.5mm

Power Supply

External Adapter: 100-240V AC, 50-60   Hz

Input Voltage Range: +12V   DC ± 5%

On Screen Display (OSD)

Control (back): Power, Auto, Up, Down, Menu

Power Consumption

≤ 20W (typ.)

Speaker

Optional

Webcam

Optional

Temperature Range

Operating: 0℃ to 50℃, storage: -20℃ to 60℃

Humidity (Non Condensing)

Operating: 20% to 80%, storage: 10% to 90%

I/O

VGA, HDMI, USB (DVI,DP optional)

Accessories

Cables: HDMI×1, USB×1, 1.8m Length

Carton Box Dimensions

500mm (L) × 150mm (W) × 375mm (H)

Weight

Net: 4Kg

Gross: 5Kg

MTBF

50,000 hours demonstrated

Agency Approvals

CCC, CE, FCC, CB, RoHS,CEC

Warranty

1 year(3/5 Years optional)
